The new standard

Charging Category	AC charging
User interface	Includes 7" high-resolution touchscreen,LED symbols
Connectivity	4G (optional),Wi-Fi,2 x Ethernet
App support	Third party
Outlet	Single- or dual type 2 outlets
Charging current	32 A
Number of phases	3 Phase
Rated voltage	400 V
Load balancing	CHARGESTORM® CONNECTED 3i supports CTEK’s NANOGRID™ LOCAL PLUS and grid controller products – a high-performance, cost-efficient dynamic load balancing solution without requiring cloud access
Energy meter	MID approved
Ground fault detection	MRCD TYPE B 30mA AC,30mA DC
Ground fault reset	Semi-automatic
Communication protocols	OCPP 1.6/OCPP 2.0.1**
Authentication	RFID,OCPP,AutoCharge,Plug & Charge**
Impact protection	IK08
Degree of protection	IP54
Compliance	CE;RED;IEC 62196;IEC 61851-1
Dimensions	161 x 281 x 416 mm mm
Net weight	11 kg
Ambient operating temperature	-30 °C to +50 °C
Warranty	3 years
Warranty information	CTEK issues a limited warranty to the original purchaser of the product. Depending on the product, the limited warranty period will vary. The limited warranty is not transferable. The warranty applies to manufacturing faults and material defects. The warranty is void if the product has been handled carelessly or repaired by anyone other than CTEK or its authorized representatives. CTEK makes no warranty other than this limited warranty and is not liable for any other costs other than those mentioned above, i.e. no consequential damages. Moreover, CTEK is not obligated to any other warranty other than this warranty.

New

CHARGESTORM® CONNECTED 3i

EV Charger

Item No. 40-638

The new standard for user-friendly public AC charging

User-friendly, integrated, 7” touchscreen with live charging data, cost transparency, and dynamic QR-code payments

Single or dual 22 kW AC outlet delivers reliable, high-power charging for public and workplace locations

Cybersecure, ISO 15118-ready platform with AutoCharge today and Plug & Charge hardware-ready

0 ( 0 reviews )

Request a quote Request a quote

New

In stock

Back in stock alert

We will send you an email when the product is back in stock again

By signing up, I agree with the data protection policy of Ctek.

The CHARGESTORM® CONNECTED 3i is an AC charger designed for public use, combining reliability, cybersecure, and ease to use. It supports the latest cybersecurity requirements, and is future-ready for smart grid integration – making it the ideal choice for modern EV infrastructure.

Specifications

Charging current

32 A

Outlet

Single- or dual type 2 outlets

Connectivity

4G (optional),Wi-Fi,2 x Ethernet

Communication protocol

OCPP 1.6/OCPP 2.0.1**

Load balancing

CHARGESTORM® CONNECTED 3i supports CTEK’s NANOGRID™ LOCAL PLUS and grid controller products – a high-performance, cost-efficient dynamic load balancing solution without requiring cloud access

Warranty

3 years
